Name: GRASL E-750-230 rack drive
Brand: Grasl
SKU: E-750-232
Price: 432.00 EUR
Availability: InStock

GRASL E-750-230 rack drive

€432,00

1/2

GRASL E-750-230 rack drive

€432,00

excl. VAT

In stock

Product code:

E-750-232

The E-750-230 electric rack drive is manufactured by Grasl. It is available in 230V and 24V versions with stroke lengths of 300/500/750 mm. The package also includes a mounting bracket with a counterpart. Input voltage 230W (230V/0,1) and force 500N/250N.

Max stroke: 750mmmm
Power: 500N
Speed: 10mm/s
Voltage: 230V

Input voltage: 230 V~ / 0.1 A (23 W)
Push force: 500 N, pull force: 250 N
Electronic overload cut-off
Duty cycle: S3 25% (according to DIN EN 60034)
An internal disconnect relay allows the actuators to be arranged in random groups or connected in parallel without interfering with each other
Stability: 3,500 N
Light grey silicone power cable, approx. 1 m length
Includes M8 eye bolt Ø6 mm, without locking screws

The actuator is also available in different variants:
E-300-230: 300 mm
E-500-230: 500 mm
E-750-230: 750 mm

24V versions:
E-300-24: 300 mm
E-500-24: 300 mm
E-750-24: 300 mm

We will be happy to help you choose the right actuator.
